StrikeIt1 operates up to two (2) 24VDC panic hardware devices simultaneously. It is designed to handle the high current surge panic hardware locking devices demand. Each lock output has an adjustable relock delay timer.
It will control a pair of doors simultaneously or independently control two individual doors. It has a follower relay for each output to trigger external relays, ADA push plate switches, etc.
Main Features
Input 115VAC 60Hz, 6.3A
Trouble relay output indicating low DC output voltage
Battery Backup, fuse rating: 25A/32V
Visual LED Indicators Green/Red
Fire Alarm Disconnect
Manual testing to allow to tests battery conditions
Adjustable panic release from 1 sec. to 30 secs
Follower and Delay relay turns off when the potentiometer selected time elapses after release of the input trigger
NOTE: Product currently out of stock which will delay delivery by 2 to 3 weeks
