Access Power Controller w/ Power Supply/Charger, 8 Fused Relay Outputs, 12/24VDC @ 4A, FAI, 115VAC, Red BC400 Enclosure.AL400ULACMR converts a 115VAC 60Hz input into eight (8) independently controlled 12VDC or 24VDC Fail-Safe and/or Fail-Secure outputs with a total of 4A @ 12VDC or 3A @ 24VDC continuous supply current.
Outputs are activated by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc.
Main Features
Eight (8) independently controlled outputs
Output options: a) Eight (8) Fail-Safe and/or Fail-Secure power outputs b) Eight (8) form "C" 5A rated relay outputs c) Any combination of the above
Eight (8) auxiliary power outputs (un-switched)
Output fuses are rated @ 3.5A
Filtered and electronically regulated outputs
Supervision: - AC Fail - Battery Fail and Battery Presence
Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the eight (8) outputs
Alarm output relay indicates that FACP input is triggered
NOTE: Product currently out of stock which will delay delivery by 2 to 3 weeks
