DSC PC4020PCBC MAXSYS PC4020 16-128 Zone Control Panel Board, PCB only. The security control panel shall have a total capacity of 128 zones. The base panel shall have a capacity of 16 hardwired zones and 112 addressable zones on two addressable loops.
The system shall be complete with a standard, non-shielded, 4 conductor station wire bus (Combus) for powering and communicating with remote hardwired system expansion modules and devices.
Main Features
Supports up to 16 hardwired keypads
Expandable up to 128 zones using hardwire, wireless modules and addressable zones
Built-in telephone line and siren supervision
16 on-board zones
Expandable to 64 wireless zones
Auto SIA and Contact ID formats
COMBUS hardwired expansion
Full upload/download support with DLS2002 software
