The alignment of the detector is extremely intuitive, fast and accurate. Both the IR transmitter and the CMOS imager are contained in the eyeball that can turn freely in all directions. The eyeball moves +/- 20 ° in the vertical direction and 50° in the horizontal direction.
Once the optimum alignment is finalised, signalled by all green arrows and LED, the eyeball is locked by tightening the lever on its side. A paintable cover is then placed over the front to hide the alignment arrows, locking mechanism and secures the locking lever in locked position.
Main Features
The alignment of the detector is extremely intuitive, fast and accurate
The eyeball moves +/- 20 ° in the vertical direction and 50° in the horizontal direction
NOTE: Product currently out of stock which will delay delivery by 2 to 3 weeks
