The GHSLF is a high quality, low profile, low frequency audible and visible appliance that offers a dependable audible and visual alarm. The GHSLF is ideal for any occupancy that requires notification appliances.
The GHSLF horn offers a 520 Hz square wave, temporal 3 tone. A jumper selection is available for normal or loud decibel tone. A temporal 4 pattern is available when used with the Gentex GTSM Synchronization Control Module. The GHSLF is available in a fixed 15, 110 and 177 candela strobe.
Main Features
Nominal voltage 24 VDC
Unit Dimensions: 6-1/2" (16.5 cm) high × 5-1/2" (14.0 cm) wide × 2" (5.0 cm) deep
Produces a 520 Hz square wave, temporal 3 tone
Fixed candela options: 15, 110 and 177
Jumper selection for normal or loud dBA
Super-Slide® Bracket - Ease of Supervision Testing
Checkmate® - Instant Voltage Verification
Prewire entire system, install mounting bracket, then install signals
Input terminals accept 12 to 18 AWG
Synchronize horn/strobe with Gentex GTSM Synchronization Control Module
Temporal 4 pattern available when used with Gentex GTSM Synchronization Module
