EIA compliant 19” wall mount rack shall be Middle Atlantic Products model # SWR-12 (refer to chart). Overall dimensions shall be 23.44” W x 25.13”/32.13” H x 12.5” D (refer to chart). Weight capacity shall be 150 lbs. Center section and backpan shall be constructed of cold rolled steel, phosphate pre-treated and finished in a black textured powder coat.
Rackrail shall be constructed of 11-gauge steel with tapped 10-32 mounting holes in universal EIA spacing with black e-coat finish and marked rackspaces.
Main Features
Available in 20” and 26” useable depths to accommodate deeper equipment
Wide range of cabinet options makes rack adaptable to a multitude of different installation environments
Ready-to-assemble design saves space and freight
Optional removable steel side panels provide security while attractive thermolaminate side panel and options provides aesthetic appeal for home and studio installations
Optional casters can be bolted directly to bottom of rack or concealed in skirted base
Unique mechanically interlocking corner joint is central to each unit’s exceptional strength and eases assembly
