MPR components shall be ETL Listed to UL Standard 5 and CSA C22.2 No.62 separately and as a system in the US and Canada. MPR shall be manufactured by an ISO 9001 registered company.
Stand-alone power modules shall be RLM-xx-1CA and shall include a 9.5’ Signal SAFE™ power cord with NEMA 5-15P plug or 5-20P plug. (See chart to determine which stand-alone power modules are suitable for your application). The MPR, RLM and M series shall be finished in durable black powder coat.
Main Features
Lightweight raceway with back-mount support clip that allows mounting in any position on a vertical or horizontal axis
Raceway available in any of (4) standard lengths or can be cut to any custom length of 2” increments. See chart on next page for usable mounting space.
Modules can be positioned anywhere along the raceway in 2” increments
Basic and controlled (dry contact) power modules available in 15A, 20A & 30A · USC-6R, MPR-SEQA, MPR-SEQ-1CA or any maintained dry contact can be used for control
Standard and isolated ground modules • NEMA, IEC, Twist-lock, and Neutrik receptacles
Convenient genderless connectors ensure fast & safe assembly (no hardwired inter-chassis connections)
An open deep raceway, with no cross divider interference ensures fast and easy assembly · Threaded grooves along length of extrusion allow attachment of cable management ties for low voltage control
