The TX3-CX-4K-A controller conveniently houses two 2-door controller boards providing a 4-door system kit. The chassis can hold up to four 2-door controller boards in total, providing the provision to add two additional 2-door controller boards to extend the number of doors.
The system comes with 4 TX3-P300-HA card readers and one IP module, which can allow property managers/programmers to program the system remotely. The system can also be connected with additional control panels using RS-485 (up to 63 boards).
Main Features
TX3 Series Access Control System can integrate with all TX3 series control panels (Keypad Voice Entry, Touch Voice Entry, Elevator Restriction), making property managers life simple and easy
A hybrid architecture that combines the best of TCP/ IP and RS-485. All panels can be networked via RS-485 or TCP/IP
The system comes with an IP module for easy local or remote programming
8 supervised inputs for a wide selection of monitoring points that can be shared between the two card readers
Each 2-door controller board can provide up to 8 programmable outputs; 6 are Form C contacts (normally open/normally closed), two powered outputs provide 12 VDC power for up to 1 ampere of current combined
The number of inputs and outputs multiply as more 2 door controller boards are added
Providing up to 32 supervised inputs + 32 programmable outputs where 24 of them are formed C relay and 8 of them are powered (when using four 2-door controller boards/8 door card access system)
The Wiegand inputs support multiple different reader types such as Proximity, MIFARE, Biometrics, iClass, and BLE (ordered separately)
