Pure sine wave inverter, adaptive battery charger, transfer relay – All in ONE unit. Samlex Evolution ™
Series inverter/chargers provide reliable AC power wherever it’s needed.
The EVO-2224 is a 2200 Watt Pure Sine inverter, 24 VDC input, 120 VAC output, 50/60 Hz. It intelligently integrates a 70 Amp 4 stage Battery Charger and a 40 Amp Transfer Relay into an advanced and affordable off-grid power solution.
Main Features
Two separate AC inputs – one for grid (priority #1), one for generator (priority #2), connect simultaneously, no need to reconfigure when different power sources are available
Each AC input is programmable for voltage and frequency. User determines what the min and max thresholds are to switch from Grid or Generator to Inverter
Generator start can be initiated by “Status Relay” contact, can be programmed to activate when grid is lost
Connect a solar charge controller directly to the EVO TM
through the Battery Charger external DC Input, seamlessly integrates solar charging into the EVO’s power system
ONLINE Mode can be used to prioritize Batteries/Inverter over the grid, ideal for those wishing to operate primarily on solar power (when the grid is available, but might be costly)
Programmable – set battery voltage thresholds to initiate charging
16ms transfer when going from Grid to Inverter. When grid is lost, the transfer relay switches to inverter at the correct place in the wave form, the transfer takes less than 16ms
NOTE: Product currently out of stock which will delay delivery by 2 to 3 weeks
